7/16 DIN Female Jack Waterproof RF Coaxial Connector for. 141" Cable IP68

Basic Info.

Model NO.	DIN-KB3D1
Classification	Female Connector
Interface Type	7/16
Shape	Strip
VSWR	≤[email protected]@ ≤[email protected]
Medium Pressure	≥4000V RMS,50Hz,at Sea Level
Brand	Four Star
Frequency Range	DC-7.5GHz
Waterproof Rate	IP68
Plating	Tri-Alloy and AG
Materials	Brass and PTFE
Impedance	50ohm
Connector Type	7/16 DIN Connector
Transport Package	300 Pieces in One Carton.
Specification	Carton (32cmx29cmx23cm)
Trademark	Four Star
Origin	China
HS Code	85369090
Production Capacity	500000 Pieces/Year

Packaging & Delivery

Package Size 19.00cm * 9.00cm * 6.00cm Package Gross Weight 0.200kg

Product Description

TYPE 7/16(L29) is one kind of thread coupling RF coaxial connector. Characteristic impedance is 50ohm. The characteristic of connector is in big power, low VSWR, less attenuation, low inter-modulation, excellent nature of airtight. They are used in connection with feeder cables in broadcast, Television,ground launch system, monitoring of radar, microwave communication fields etc. Our company manufacturer produces many kinds of jumper lines, which can reduce your cost on cable.

7/16 DIN Female Connector For .141" Cable
Model No.	DIN-KB3D1
Interface	IEC 60169-4 /DIN47223/CECC22190
Electrical
Characteristic Impedance	50ohm
Frequency Range	DC-7.5GHz
VSWR	≤[email protected]@ ≤[email protected]
Intermodulation 3rd (PIM3)	≤ [email protected]×20W
Insertion Loss	≤[email protected]
Working Voltage	≤2700V RMS,50Hz,at sea level
Dielectric Withstanding Voltage	≥4000V RMS,50Hz,at sea level
Dielectric Resistance	≥10000MΩ
Contact Resistance	Center Contact ≤0.4mΩ	Outer Contact ≤1.0 mΩ
Mechanical
Durability	Mating cycles ≥500
Material and Plating
Parts Name	Material	Plating
Body	Brass	Tri-alloy
Insulator	PTFE	-
Spacer	PTFE	-
Center Conductor	Phosphor copper	Ag
Environmental
Operating Temperature	-55ºC~+125ºC
Weatherproof Rate	IP68
RoHs	Compliant

Our Service

1.Reply your enquiry within 24 hours.

2.Payment model: T/T, L/C,Paypal and Western Union

3.Many Shipping models: By Air, By Sea, Express(DHL, Fedex, TNT UPS...)

4.Lead(Delivery) time: Normally 14 days after getting order

5.Port of loading: Shanghai, Ningbo and Shenzhen.

6.Guarantee Period : Within 12 months after shipment.

7.Operating guide(Instruction)upon request.

8.Customized drawing ,sample and package can be done.
